Name
5"-16.2" Slit Coating LOCA Lamination Machine
-
Applications
LOCA based lamination for medium/small-sized single-screen and multi-display automotive screens
-
Product Size
CG: 187×129mm~438×300mm
LCD/LCM: 167×109mm~386×230mm
CG: 187×129mm~438×300mm
LCD/LCM: 167×109mm~386×230mm
-
Efficiency
≤30s/pcs (400μm adhesive thickness)
-
Equipment Accuracy
±0.15mm，CPK≥1.33
-
Equipment Dimensions
L20805×W2600×H2620mm (For reference only)
-
Technological Advantages
Technological Advantages Proprietary high-precision coating system features strictly analyzed coating head pressure/fluid dynamics, enabling customized parameter configurations based on client-specific adhesive properties. Leveraging Liande's proven lamination expertise, the machine enables sectional process control with real-time depth/pressure feedback, effectively controls bubble/Mura defects. Integrated AOI inspection module provides real-time quality monitoring.
-
Technological Process
Loading → Film Peeling → Plasma → Taifun → Thickness Measurement → Slit Coating → Activation → Laminating → Debubbling → AOI → Pre-curing → Unloading
5"-16.2" Slit Coating LOCA Lamination Machine
The 5-16.2" slit coating LOCA lamination machine laminates LCD/LCM modules to CG(cover glass) via liquid optical adhesive, with process flow: loading, film peeling, plasma treatment, taifun, thickness measurement, slit coating, activation, laminating, debubbling, AOI inspection, primary curing, and unloading.
Technical Specification
