Name
Smartphone Foldable Display Hinge Torque & Endurance Testing Equipment
-
Applications
In-line folding endurance testing during automated production of foldable smartphones
-
Product Size
Testing Range: 65×160mm ~ 180×200mm
Maximum Compatibility with Smartphone Size: 180×200mm
-
Efficiency
≤25.5 sec/unit (configurable based on folding cycles)
-
Equipment Accuracy
Angular Control: 0-180° adjustable (±0.1° accuracy)
Bending Velocity: ≥10,800°/min (continuously variable)
-
Equipment Dimensions
L1000×W1900×H1800mm (For reference only)
-
Technological Advantages
Proprietary high-precision folding fixture and stable control testing system with reliability;
Folding jig with precision-calibrated tooling system could control well the folding angle/speed based on customer's parameters;
Integrated hinge torque monitoring module with monitor in real-time
-
Technological Process
Conveyor Loading → Flipping → Code Scanning → Imaging (Poka-Yoke Inspection) → Robotic Handling → Hinge Torque & Endurance Test → Robotic Unloading → Conveyor Lift-Up Unloading
Smartphone Foldable Display Hinge Torque & Endurance Testing Equipment
Smartphone Foldable Display Hinge Torque & Endurance Testing Equipment, designed to evaluate screens' folding reliability while monitoring hinge torque parameters in real-time during folding cycles.
Technical Specification
